Glassware Washer LGW-A12 is developed with a high-pressure hot air-drying system for cleaning with an inlet water pressure of 0.3 to 0.8 MPa. Provided with a 320L capacity, it employs an air heater for washing and a HEPA filter for drying. Enhanced with an efficient pump for effective circulation of cleaning solutions. It includes 12 pre-set programs, with the flexibility to customize one program for optimized performance.
Request Quote| Capacity | 320 L |
| Washing Temperature | Upto 99℃ |
| Drying Temperature | Upto 120℃ |
| Water consumption/cycle | 15 L |
| Inlet Water Pressure | 0.3 to 0.8 MPa |
| Washing Chamber Size (W × D × H) | 600 × 629 × 820 mm |
| Noise | ≤ 55 dB |
| Overall Power Consumption | 6.5 kW/ 18 kW |
| Water Washing Power Consumption | 1.5 kW |
| Water Heating Power Consumption | 5/ 15 kW |
| Drying Power Consumption | 3.6 kW |
| Cleaning Racks | 3 pcs |
| Standard Cleaning Racks | 36 nozzles std. 3 racks |
| Power Supply | AC220V, 50Hz; 380V, 50Hz |
| External Size (W×D×H) | 790×690×1950 mm |
| Package Size (W×D×H) | 1000×840×2180 mm |
| Gross Weight | 350 kg |
Glassware Washer is used for washing of various glassware like beakers, pipettes, tubes, plates, dishes etc. in microbiology, biotechnology laboratories, research centres and clinical laboratories.
One bucket RBSA150, (1 L)
One bucket RBS A375 neutralizer (1 L)
USB interface
Cleaning racks
| Model | Capacity | Washing Temperature | Drying Temperature | Water consumption/cycle | Inlet Water Pressure | Washing Chamber Size (W × D × H) | Noise | Overall Power Consumption | Water Washing Power Consumption | Water Heating Power Consumption | Drying Power Consumption | Cleaning Racks | Standard Cleaning Racks | Power Supply | External Size (W×D×H) | Package Size (W×D×H) | Gross Weight |
| LGW-A20 | 220 L | - | - | 15 L | - | - | <60 dB | - | - | - | - | - | - | - | - | - | - |
| LGW-A21 | 320 L | - | - | 18 L | - | - | <60 dB | - | - | - | - | - | - | - | - | - | - |
| LGW-A22 | 420 L | - | - | 25 L | - | - | <60 dB | - | - | - | - | - | - | - | - | - | - |
| LGW-A10 | 120 L | Upto 99℃ | Upto 120℃ | 15 L | 0.3 to 0.8 MPa | 600 × 629 × 465 mm | ≤ 50 dB | 6 kW | 0.75 kW | 5 kW | 2.1 kW | 1 pcs | 36 nozzles std. 1 rack | AC220V, 50Hz | 960×740×850 mm | 1100×950×1050 mm | 145 kg |
| LGW-A11 | 220 L | Upto 99℃ | Upto 120℃ | 20 L | 0.3 to 0.8 MPa | 600 × 629 × 690 mm | ≤ 55 dB | 6 kW/ 17 kW | 0.75 kW | 5/ 15 kW | 3.6 kW | 2 pcs | 36 nozzles std. 2 racks |
AC220V, 50Hz; 380V, 50Hz(Standard); 110V,60Hz(Optional) |
690 × 790 × 1820 mm | 790 × 940 × 1990 mm | 300 kg |
| LGW-A12 | 320 L | Upto 99℃ | Upto 120℃ | 15 L | 0.3 to 0.8 MPa | 600 × 629 × 820 mm | ≤ 55 dB | 6.5 kW/ 18 kW | 1.5 kW | 5/ 15 kW | 3.6 kW | 3 pcs | 36 nozzles std. 3 racks | AC220V, 50Hz; 380V, 50Hz | 790×690×1950 mm | 1000×840×2180 mm | 350 kg |
